Turn any ComfyUI workflow into a callable API with one click.
A ComfyUI custom-node plugin that publishes a workflow to Runflow as a stable HTTP endpoint. The plugin captures the workflow graph, the runtime manifest (ComfyUI commit, custom-node commits, package versions, cached-model state), and uploads it to Runflow — no Dockerfile, no GPU provisioning, no glue code.
Documentation · API Reference · Pricing · Releases
Public beta. The plugin, API surface, and pricing are stable but subject to change. Pin a commit SHA if you need version guarantees, and watch the changelog for breaking changes.
ComfyUI persists widget values into the workflow JSON, so a key entered into the Deploy node's api_key widget travels with every export, screenshot, paste, and bug-report attachment. Configure your key under Settings → Runflow → Connection instead — those values are machine-local and never written to workflow files. Before deploying any imported workflow, clear both the host and api_key widgets (or recreate the node).
The Auto setup button executes git clone and pip install against URLs declared by the loaded workflow. Treat it like running an untrusted shell script — only enable it for workflows from sources you trust.
If you start ComfyUI with --listen and the port is reachable from the public internet, anyone who finds it can run code on your machine. Use the built-in port-exposure scan (below) and enable password auth before exposing the server.
- Install the plugin — clone into
custom_nodes/and restart ComfyUI. - Configure credentials — Settings → Runflow → Connection, paste your API key.
- Deploy — drop a Runflow Deploy node into your workflow, name your endpoint, click Deploy.
- A working ComfyUI installation.
- A Runflow API key with the right scopes (see below).
python,pip, andgiton PATH (only needed for the optional Auto setup).
| You want to… | Required scopes |
|---|---|
| Publish a new endpoint | comfyui-workflows:read + comfyui-workflows:create |
| Redeploy / iterate on an existing endpoint | …add comfyui-workflows:edit |
| Delete endpoints from this client | …add comfyui-workflows:delete |
The plugin sends Authorization: Bearer <key> and lets the API derive your organization from the key — no organization UUID needed.
cd <ComfyUI>/custom_nodes
git clone https://github.com/runflow-io/ComfyUI-Runflow.git
# Or, for development against this checkout:
ln -s /path/to/ComfyUI-Runflow ComfyUI-RunflowA full ComfyUI process restart is required (browser refresh is not enough). After restart, a Runflow category appears in the node picker.
Open Settings → Runflow → Connection:
| Setting | Default | What it is |
|---|---|---|
Runflow.ApiUrl |
https://api.runflow.io |
Runflow API base URL. Override only for a local/staging stack. |
Runflow.ApiKey |
(empty) | A rf_live_* API key issued for your organization. |
Both fields can also be overridden per-workflow on the Deploy node's host / api_key widgets — but see the security warning above before doing so.
- Add a Runflow Deploy node from the Runflow category.
- Set its
endpoint_namewidget. The slug is derived from this name (lowercased, spaces → hyphens, non-alphanumeric stripped). Example:Background Removal v2.1→background-removal-v21. - Click Deploy.
A Deployed ✓ toast confirms success; failures surface as browser alerts with the error body. The HTTP response is the terminal state — there is no separate deployment job to poll.
Renaming
endpoint_namecreates a new endpoint. Keep the name stable to redeploy onto the same slug.
The Local Playground button (directly below Deploy on the Runflow Deploy node) opens a clean, brand-styled web app on the same ComfyUI host that lets you exercise the workflow through its Runflow Input / Runflow Output surface — a form on the left, a media preview on the right — without ever touching the node graph. Useful for sanity-checking what your API actually looks like before you ship it.
Open it: click Local Playground on the Deploy node. A new tab opens at http://<comfy-host>/runflow/playground/<slug>, where <slug> is derived from endpoint_name the same way Deploy derives it (Background Removal v2.1 → background-removal-v21).
Form: generated from the workflow's Runflow Input (…) nodes. The display_name widget is the field label, the description widget is the helper text, the required widget (on by default) controls whether the field must be filled before Run is allowed, and the input type comes from the node class. Booleans render as a switch; numbers as a number input; images as a file picker that uploads through ComfyUI's built-in /upload/image (the file lands in ComfyUI/input/, and the uploaded filename is what the workflow receives); files as a file picker that uploads through Runflow's /runflow/upload-input-file (same ComfyUI/input/ destination, any file type).
Run: click Run. The plugin takes a copy of the captured workflow, disconnects the value link on every Runflow Input node — exactly the same scrubbing rule Deploy uses to detach the local test wiring — and replaces it with the form value (or, for image inputs, a freshly-injected LoadImage node pointed at the uploaded file). The graph then runs against the local ComfyUI via /prompt, drains /ws until completion, and pulls outputs from /history.
Preview: the right panel renders per Runflow Output:
Runflow Output (Image)→ inline imageRunflow Output (File)chained from a video saver → inline<video controls>Runflow Output (File)chained from an audio saver → inline<audio controls>Runflow Output (File)for.glb/.gltfmeshes → in-browser 3D viewer (<model-viewer>, lazy-loaded from a CDN the first time a 3D output appears)- Anything else (
.obj,.ply,.stl, archives, etc.) → download link
Captures are in-memory. Restarting ComfyUI clears the playground; click Local Playground again to recapture. Editing the graph after capture also drifts — the playground always runs the captured graph, so reopen if you've changed things.
Auth: if you've enabled password authentication in the Runflow security panel, the same Basic-auth prompt that protects the rest of ComfyUI also protects the playground page and its run endpoints.
The button is intentionally a local-only tester. To run a workflow through the public Runflow API, use Deploy and call the endpoint over HTTPS as documented under Calling your deployed workflow.
Place a typed Runflow Input (…) node for each value your endpoint accepts and a Runflow Output (…) node for each artifact it returns. The input_id / output_id widgets are the stable keys callers use against the API.
| Node | Class | Default ID |
|---|---|---|
Runflow Input (String) |
RunflowInputString |
string_input |
Runflow Input (Int) |
RunflowInputInt |
int_input |
Runflow Input (Float) |
RunflowInputFloat |
float_input |
Runflow Input (Boolean) |
RunflowInputBoolean |
boolean_input |
Runflow Input (Image) |
RunflowInputImage |
image_input |
Runflow Input (File) |
RunflowInputFile |
file_input |
Locally each input is a pass-through; at deploy time the rewriter injects caller-supplied values. Use the display_name and description widgets to label the field in the Runflow playground — they are presentation only and never change the API contract (callers always key inputs by input_id, and description is not part of the API schema). The required widget (on by default) marks whether a value must be supplied; turn it off for optional inputs so the workflow's own node default applies when a caller omits the value. The label, the helper text, and the required flag are all honored by both the local playground and the Runflow site.
Runflow Input (File) behaves as a plain string (a filename) inside the graph, so any loader that takes a file path can consume it. Use its 📁 Choose file button to upload a local file into ComfyUI/input/ — the chosen file_name becomes the node's output locally and the deploy default. On the Runflow site the field renders as a file upload.
| Node | Class | Default ID | What it does |
|---|---|---|---|
Runflow Output (Image) |
RunflowOutputImage |
image_output |
Saves each image in the batch as PNG to output/. |
Runflow Output (File) |
RunflowOutputFile |
file_output |
Marks a file already written under output/ (by an upstream save-* node) as the run's deliverable. Use for video, 3D meshes, audio, archives, etc. |
These nodes encode native ComfyUI sockets to a file in output/ and emit the relative filename on a STRING socket — wire that into Runflow Output (File).
| Node | Input | Format / codec |
|---|---|---|
Runflow Save Audio (FLAC) |
AUDIO | FLAC, lossless |
Runflow Save Audio (MP3) |
AUDIO | MP3 / libmp3lame, with quality widget (V0, 128k, 320k) |
Runflow Save Audio (Opus) |
AUDIO | Opus / libopus, with bitrate widget (64k–320k) |
Runflow Save Video (MP4) |
VIDEO | MP4 / H.264 (delegates to VIDEO.save_to) |
Runflow Save Video (WEBM) |
IMAGE batch + fps | WebM / VP9 or AV1 — mirrors stock ComfyUI's SaveWEBM input shape |
The audio nodes delegate to ComfyUI's AudioSaveHelper, so encoding stays in lockstep with stock Save Audio. The MP4 node calls the VIDEO socket's own save_to(...). The WEBM node uses PyAV directly because the VIDEO socket only supports MP4/H.264 today.
These nodes require a recent ComfyUI (comfy_api.latest module). On older installs they're skipped at load with a single warning — the rest of the plugin still works.
Once deployed, the workflow is available as an HTTP endpoint:
POST https://api.runflow.io/v1/comfyui-workflows/{owner}/{slug}/runs
curl -X POST https://api.runflow.io/v1/comfyui-workflows/your-org/your-endpoint/runs \
-H "Authorization: Bearer $RUNFLOW_API_KEY" \
-H "Content-Type: application/json" \
-d '{
"input": {
"prompt": "a sea otter holding a smooth pebble, studio photography",
"width": 1024,
"height": 1024
},
"callback_url": "https://your-server.com/webhook"
}'{
"id": "01J0...",
"status_code": "succeeded",
"output": {
"kind": "comfyui_outputs",
"outputs": [
{
"output_id": "image",
"url": "https://...",
"content_type": "image/png",
"size_bytes": 1048576
}
]
}
}Output URLs are presigned and time-limited — download or rehost immediately. See Runs for the full lifecycle (polling, callbacks, retries) and Verify Callback Signatures for HMAC verification of webhook payloads.
Runs are billed per second of GPU time. By default the platform picks the cheapest GPU that fits the workflow's memory requirements; you can pin a specific model via PATCH /v1/comfyui-workflows/{id}.
The available GPU types and their per-second rates are listed at runflow.io/pricing — check there before sizing a budget. Workers scale to zero when idle, so the next run after a quiet period pays a 10–40s cold-start. For latency-sensitive workloads, schedule warming runs or keep a playground tab open.
The Auto setup button (directly below Deploy on the Runflow Deploy node) installs every custom node and downloads every model the active workflow needs. Useful when you load someone else's workflow and don't want to chase dependencies by hand.
Clicking the button opens a modal with two checkboxes — Install missing custom nodes and Download missing models — and a Start button. While the job runs, the modal shows a byte-progress bar for the current download and a count-progress bar for the current custom-node install. Models and custom nodes run in parallel.
When the job finishes, click Restart ComfyUI in the modal: the server re-execs itself, the modal waits for it to come back, and the page full-reloads so the newly installed nodes register.
Auto setup assumes python, pip, and git are on PATH. It uses git clone --depth=1 + git fetch --depth=1 origin <sha> + git checkout <sha> (falling back to a full clone if the host disables SHA-targeted fetches), then python -m pip install -r requirements.txt if the cloned repo carries one. Works on Linux, macOS, and Windows.
Trust the workflow before clicking. Auto setup will execute arbitrary URLs declared by the workflow file.
ComfyUI ships no authentication by default, and custom nodes can execute arbitrary code on the host. If you start ComfyUI with --listen (binding to 0.0.0.0 — all network interfaces) and the port is reachable from the public internet, anyone who finds it can run code on your machine. The Runflow security panel helps you detect and close that exposure.
| Setting | Default | What it does |
|---|---|---|
Enable password authentication |
off | Require HTTP Basic auth for all requests to this ComfyUI server. |
Username / Password |
(empty) | Credentials checked by the auth layer. |
When enabled with both fields set, a Basic-auth middleware guards every route. Credentials are stored in runflow_security.json next to your ComfyUI install. Browsers prompt once and cache the credentials for the session.
Click Run security scan in the same panel to check whether this machine is exposed from the public internet:
- It reports ComfyUI's listen binding (read locally from ComfyUI's
--listen/--portargs). Binding to0.0.0.0/::is flagged in red;127.0.0.1is green. - It looks up your public IP (via
api.ipify.org, falling back toifconfig.me,icanhazip.com, andcheckip.amazonaws.com). - It asks the public service portchecker.io whether ComfyUI's port (plus
80,8080,443) is reachable from the internet, and shows each port as OPEN or closed.
Privacy note: the scan sends your public IP address to portchecker.io so it can probe your ports from the outside. No workflow data is sent. If portchecker.io is unreachable, the scan still reports the local listen-binding status so you aren't left without a signal.
If a port shows OPEN (or you're bound to all interfaces), close the exposure by any of:
- Enabling password authentication above.
- Restricting access with a firewall / security group, or putting ComfyUI behind an authenticated reverse proxy.
- Binding to localhost only — start ComfyUI without
--listen(or with--listen 127.0.0.1).
| Symptom | Fix |
|---|---|
| No Runflow category in the node picker | Fully restart the ComfyUI process, not just the browser. |
Unconfigured key or URL alert |
Verify Runflow.ApiKey in Settings → Runflow → Connection; save and retry. |
401 Unauthorized |
API key is missing, revoked, or for the wrong environment. Reissue and re-save. |
lookup failed or 403 on redeploy |
Key needs comfyui-workflows:read, create, and edit scopes. |
endpoint_name must be URL-safe |
The slug came out empty after character stripping. Use alphanumerics and spaces/hyphens. |
| Workflow runs locally but fails on Runflow | Models or custom nodes aren't on the worker — run Auto setup locally first so the deploy manifest is complete. |
| Slug changed unexpectedly | Renaming endpoint_name creates a new endpoint. Keep the name stable to redeploy onto the same slug. |
- Pick a Model — decision tree for choosing a model
- Runs — lifecycle, polling, callbacks
- Verify Callback Signatures — HMAC verification for webhooks
- JavaScript SDK — typed client library
Issues and pull requests are welcome on GitHub. For account, billing, or production-deployment help, contact Runflow support through docs.runflow.io.
